Engine
-
Engine Brand: Kohler®
-
Engine Model: Professional-grade KT724
-
Engine Displacement: 747cc
-
Engine Output: 24 HP
-
Starter Type: Electric
-
Fuel Tank Capacity: 3 gal. easy fill, rustproof
-
Cylinders/Material: Twin/Cast-iron sleeve
-
Engine Start: Key
-
Engine Oil Capacity: 2 qt.
-
Lubrication: Fully pressurized, automotive-style oil pump w/ spin-on oil filter
-
Charging System: Flywheel Alternator – 12 amp regulated
-
Fuel Gauge: Fuel sight window
-
Governor: Manual
-
Choke: Choke-a-matic
-
Air Filter: Dual element
-
Oil Filter: Yes
-
Battery: 210 cold crank amps AGM
-
Drive System
-
Transmission: Hydrostatic, foot
-
Forward Speed: 5.5 mph
-
Reverse Speed: 3.1 mph
-
Rear Axle: 3/4″ w/dual PM steel drive hubs
-
Transmission Housing: Cast aluminum
-
Transmission Type: Tuff Torq K46
-
Engine to Transmission: Heavy-duty belt
-
Cutting Deck
-
Deck Cutting Width: 54″
-
Cutting Modes: Discharge/mulch/bagging
-
Deck Wash: Patented SmartJet™ high-pressure deck washing system
-
Deck Material: 11-gauge fabricated steel
-
Deck Attach/Removal: QuickAttach™ (no tools required)
-
Deck Engagement (PTO): Electronic fingertip engagement
-
Deck Construction: Fabricated
-
Spindle Construction: 3/4″ with steel cap and Triple Lip Sealed
-
Blade(s): Triple Blade
-
Deck Lift: Lever
-
Cutting Height Range: 1″ – 4″
-
Anti-Scalping; 2 Ball/2 Ball/Nose Roller
-
Deck Positions: 12-position
-
Chassis
-
Frame: defense system Fully robotically-welded frame with new e-coating corrosion
-
Front Axle(s): Cast iron
-
Turning Radius: 16″
-
Front Tires: 16″ x 6.5″
-
Rear Tires: 22″ x 9.5″
-
Bumper: Single-tube
-
Rear Tow Hitch: Included
-
Corrosion Protection: E-coating
-
Controls
-
Cruise Control: Soft touch engagement
-
Handle: Optimized steering system, manual sector and pinion/16″
-
Brakes: Automotive-style disc
-
Steering: Control Manual sector and pinion
-
Headlight(s): 2 – LED
-
Display: Hour meter
-
Comfort
-
Seat Type: 15″ high-back seat
-
Seat Suspension: Seat spring
-
Seat Adjustment: Lever
-
Floor Mats: Traction Pad
-
Dimensions
-
Weight (approx.): 520 lbs.
-
Wheelbase: – 47″
-
Additional Specifications
-
Mulch Kit: Optional
-
Discharge Chute: Included
-
Cup Holder: Included
-
Operator Presence System: Included
-
Bagger: Optional
-
Model Number: 13AQA2CTMA10
-
Warranty
-
Warranty: 3-year/unlimited hour warranty
-
Frame Warranty: 5-year/unlimited hour warranty
-
Front Axle Warranty: 5-year/unlimited hour warranty
-
Deck Shell Warranty: Limited lifetime warranty
