Engine
-
Engine Brand: Cub Cadet®
-
Engine Displacement: 547cc
-
Fuel Tank Capacity: 3.0 gal.
-
Cylinders/Material: Single
-
Engine Start: Key
-
Engine Oil Capacity: 1.8 qts.
-
Charging System: 15 amp regulated
-
Fuel Gauge: No
-
Choke: Choke-a-matic
-
Oil Filter: Yes
Battery
-
Battery: 12V 210 cold crank amps
-
Battery : AGM (Absorbent Glass Mat)
Drive System
-
Transmission: Hydrostatic, foot
-
Forward Speed: 5.5 MPH
-
Reverse Speed: 3.1 MPH
-
Rear Axle: 3/4″
-
Transmission Housing: Aluminum
-
Transmission Type: Tuff Torq TL-200
-
Rear Wheels: 20″x 8″-8″ Turf Saver
- Front Wheels: 15″x 6″-6″ Turf Saver
Cutting Deck
-
Deck Cutting Width: 42″
-
Deck Wash: Included
-
Deck Material: Steel, 13-gauge
-
Deck Attach/Removal: QuickAttach™ (no tools required)
-
Deck Engagement (PTO): Manual lever
-
Deck Construction: Stamped
-
Blade(s): 2
-
Deck Lift: Lever
-
Cutting Height Range: 1″ – 4″
-
Anti-Scalping: 2 gauge wheels
-
Deck Positions: 12 positions
Warranty
-
Warranty: 3-year/unlimited hour warranty
-
Frame Warranty: 5-year/unlimited hour warranty
-
Front Axle Warranty: 5-year/unlimited hour warranty
-
Deck Shell: 3-year unlimited hours
-
Commercial Warranty: No
Chassis
-
Frame: Robotically welded
-
Bumper: No
-
Front Axle: Cast iron
-
Turning Radius: 16″
-
Rear Tow Hitch: Included
-
Corrosion Protection: Yes
Controls
-
Cruise Control: Yes
-
Brakes: Disc
-
Steering Control: Manual sector and pinion
Comfort
-
Seat Type: 15″ high-back seat
-
Armrests: No
-
Seat Adjustment: Lever
-
Floor Mats Traction: Rubber
Additional Specifications
-
Mulch Kit: Available Separately 19A30046100
-
Hour Meter: Available Separately 490-900-C075
-
Headlight(s): 2 – LED
-
Discharge Chute: Included
-
Cup Holder: Included
-
Operator Presence System: Included
-
Bagger: Optional
-
Model Number: 13A6A9TS010
