Engine
-
Engine Brand: Kawasaki®
-
Engine Model: FR Series
- Engine Model Number:
-
Engine Displacement: 726cc
-
Engine Output: 21.5HP
-
Starter Type: Electric
-
Fuel Tank Capacity: 3.5 gal. US (13.25 L)
-
Cylinders: Twin
-
Engine Start: Ignition Key
-
Engine Oil Capacity: 2.1qt. US (1.89 L)
-
Lubrication: Fully pressurized
-
Charging System: 12 amp regulated
-
Fuel Gauge: No
-
Governor: Mechanical
-
Choke: Separate Choke
-
Air Filter: Dual element
-
Oil Filter: Yes
-
Fuel Delivery: Carburetor
Battery
-
Battery: 230 CCA
-
Battery Type: Lead Acid
-
Battery Voltage: 12V
Drive System
-
Transmission: Hydro-Gear EZT 2200
-
Forward Speed: 7 MPH / 11.3 km/h
-
Reverse Speed: 3.5 MPH / 5.6 km/h
-
Drive System: Hydrostatic
Cutting Deck
-
Deck Cutting: Width 42 in
-
Deck Wash: No
-
Deck Material: 11-gauge steel
-
Deck Engagement: (PTO) Electric
-
Deck Construction: Fabricated
-
Blade(s): 2
-
Deck Lift: Foot pedal with Dial Adjust
-
Cutting Height Range: 1” – 4.5”
-
Anti-Scalping: 2 gauge wheels
-
Deck Positions: 15
Warranty
-
Residential Warranty: 3-year unlimited hours
-
Frame Warranty: Lifetime Limited
-
Deck Shell Warranty: Lifetime limited
-
Commercial Warranty: No
Chassis
-
Frame: 2” x 2” tubular steel
-
Turning Radius: 0°
-
ROPS: No
-
Rear Tow Hitch: Yes
-
Corrosion Protection: Yes
Controls
-
Cruise Control: No
-
Brakes: Disc
-
Steering Control: Steering Wheel
Comfort
-
Seat Type: 20″ Cut-and-Sew with Head Bolster
-
Armrests: No
-
Seat Adjustment: Knob
-
Front Caster Suspension: No
Wheels
-
Rear Tires: 20”x 8”-8″
-
Front Tires: 13″x 6.5″-6″
-
Tire Tread: Turf Armor
Additional Specifications
-
Hour Meter: Yes
-
Mulch Kit: Available separately
-
Headlight(s): LED
-
Cup Holder: Yes
-
Operator Presence System: Yes
-
Parking Brake: Hand lever
-
Model Number: 17CIGBYEA10
