Engine Brand: Kawasaki
-
Engine Model: FX Series EFI FXT00V-BS42
-
Engine Displacement: 999cc
-
Engine Output: 38.5 HP
-
Fuel Tank Capacity: Twin 7.45 gal. tanks (14.9 gal. total)
-
Charging System:15 amp regulated
-
Fuel Delivery: Electronic Fuel Injection (EFI)
Drive System
-
Transmission: Hydro Gear 5400
-
Forward Speed; 14 mph
-
Reverse Speed: 6 mph
Cutting Deck
-
Deck Cutting Width: 60”
-
Deck Material: fabricated 7ga. (.187”) steel shell
-
Deck Engagement (PTO): electronic fingertip engagement pto
-
Deck Construction: 7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge
-
Spindle Construction: 8″ sealed cast aluminum housing (maintenance-free)
-
Blade(s): Triple-blade / High-lift blade (standard) Marbain Blade
-
Cutting Height Range: 1″ – 5″
-
Anti-Scalping: 2 front deck gauge wheels
-
Deck Positions: Foot pedal with spring assist, 16 Positions
Chassis
-
Frame: Fully welded, full-length 3/8 x 5″ laser cut steel / integrated tie-down slots
-
Front Axle(s): 2″ x 3″ solid axle tube with ISO dampening suspension
-
Front Tires: 15″x6″-6″Reliance Carlisle run flat
-
Rear Tires: 26″ x 12″ – 12″
-
Tire Tread: Turf Tread
-
ROPS: 2″ x 2″ spring-latch tool-less foldable 3 position
-
Bumper : 5/16″ Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
-
Yokes: 1/2″ thick steel front yokes
Controls
-
Brakes: Hand-operated lever with integrated hydro pump release lever
-
Steering Wheel Control: High Performance & Speed Control
Comfort
-
Seat Type: Cushion with seat belts
-
Arm Rests: Padded arm rests
-
Seat Suspension: High-back Air-Ride suspension with EVC cushion, ISO mounted base (lateral suspension)
-
Seat Adjustment: Angle back adjust and lumbar support
Dimensions
-
Dimensions: L/W/H 86″ L x 74″ W x 52″ H
-
Weight (approx.): 1591 lbs.
Additional Specifications
-
Hour Meter: Crew Boss
-
Discharge Chute: High-density, impact-resistant rubber
-
Cup Holder: Intergrated into Side Pod
-
Model Number: 53FLHUTV050
Warranty
-
Residential Warranty: 3-Year / No Hour Limit Warranty and/or 5-Year 1,200 Hour
-
Commercial Warranty: 3-Year / No Hour Limit Warranty and/or 5-Year 1,200 Hour
